Contact Probes

Plunger: Beryllium Copper, Gold-plated

Spring: Stainless Steel

Barrel: Brass, Gold-plated

Request a Quote Contact Us

Features

Leads
Lands or Pads
Pads
Plated
- A
Concave
 - H
Serrated
- B
Spear point
- U
4-Pointed Crown

- D
Spherical
- J
Spherical Radius
- E
Convex

- K
Chisel


Series
Test Center (mm)
Max. Travel (mm)
Spring force at Working Travel (g)
Rated Current (A)
Resistance (mOhm)
Operating Temperature Range (°C)
Packing (pcs/ polybag)
P50
1.27
2.65
80
3
50
-45 ~ 140
100
P75
1.90
2.54
128
3
50
-45 ~ 150
100
P100
2.54
6.30
150/ 250
3
50
-45 ~ 150
100
P125
3.17
6.35
110/ 200/ 250
3
50
-45 ~ 150
100
